1520-8M-20 D&D Powerdrive Timing Belt

Description

One New Aftermarket 1520-8M-20 D&D Powerdrive Timing Belt
Manufacturer Part#: 1520-8M-20

PACKAGED UOM: 1 Each

TECHNICAL SPECIFICATIONS: Series: 8M (8 mm), Belt Type: Single Sided, No. Of Teeth: 190, Widths: 20 mm, Outside Length: 1520 mm, Manufacturer: D&D Powerdrive

FEATURES & BENE Fits

• Extra highly flexible neoprene backing provides excellent abrasion and wear resistance
• Backing also guards the tensile cords against oil, grease, dirt and moisture
• Belts constructed with fiberglas tensile cords which quarantee diemensional stability to eliminate take up adjustments
• Teeth are oil and heat resistant
• Neoprene teeth have a shear resistance equal to the tensile strength of the belt
• Tooth design provides a constant circular pitch to assure full surface contact between belt and pulley

Additional Information: Width: .787″ (20mm)Length: 59.84″ (1520mm)Section: 8MFiberglass Cord
